Type PS pneumatic clamping units
for drawback collets
art. no. |
a x b |
center height H |
D |
axial height |
max. th. bore |
max. clamping-ø |
collet type |
piston surface cm² |
weight kg |
PS 8 |
85 x 55 |
70 |
110 |
70 |
8 ø
|
10 ø x 30
|
319 E |
47 |
3,5 |
PS 9 |
85 x 55 |
70 |
110 |
80 |
11 ø
|
14 ø x 35
|
330 E |
47 |
3,5 |
PS 10 |
110 x 75 |
90 |
140 |
100 |
18 ø
|
20 ø x 45
|
359 E |
70 |
8,5 |
PS 11 |
110 x 75 |
90 |
140 |
110 |
22 ø
|
25 ø
|
367 E |
70 |
8,5 |
PS 15 |
130 x 90 |
115 |
190 |
110 |
22 ø
|
25 ø
|
367 E |
168 |
17,0 |
PS 17 |
130 x 90 |
115 |
190 |
120 |
38 ø
|
42 ø
|
390 E |
148 |
19,0 |
for deadlength collets
art. no. |
a x b |
center height H |
D |
axial height |
max. th. bore |
max. clamping-ø |
collet type |
piston surface cm² |
weight kg |
PS 4 |
85 x 55 |
70 |
110 |
80 |
12 ø
|
12 ø
|
136 E |
44 |
3,5 |
PS 5 |
85 x 55 |
70 |
110 |
80 |
15 ø
|
15 ø
|
140 E |
44 |
3,5 |
PS 13 |
110 x 75 |
90 |
140 |
105 |
22 ø
|
24 ø
|
148 E |
65 |
8,5 |
PS 14 |
110 x 75 |
90 |
140 |
105 |
26 ø
|
26 ø
|
161 E |
65 |
8,5 |
PS 18 |
130 x 90 |
115 |
190 |
125 |
42 ø
|
42 ø
|
173 E |
148 |
15,0 |
PS 19 |
130 x 90 |
115 |
190 |
125 |
60 ø
|
60 ø
|
185 E |
126 |
16,0 |
- drawback collets are especially suited for applications using short workpieces
- allows close length tolerances to be reached regardless of variations in the diameter of the workpieces being used
- can be modified for stepped collets
- integrated 3/2-path control valve remote valves may also be used to open the collet
